The Main Performance Index
2.1 Input Power Supply: AC：220V·25A,50Hz.
2.2 Output Current: AC：1000A·5V or 500A·10V.
2.3 LCD Screen Digital Display: Simultaneous display of primary current and secondary current as well as the turn ratio;
The Range of Primary Current: 0~1100A, Resolution：0.1A;
The Range of Secondary Current: 0～6A; Resolution：0.001A.
Stopwatch: 0.0001～999.99S precision ±5 significant figures.
2.4 Precision: TRUE RMS ±0.5%.
2.5 Duplicate Protection (electronic overload protection and software protection).
2.6 Usage Environment: Temperature -10~40℃
Relative humidity:<80%.
2.7 Volume; 430×260×260mm3.
2.8 Weight: 28kg.
