Detector

High performance Sipin detection module

Excitation source

45kv / 200uA silver target / tungsten target end window integrated micro X-ray tube and high voltage source

Element detection range

Elements with atomic numbers ranging from 20 to 92 calcium (mg) to uranium (U)

2. Analysis of main elements in alloy:Ti，V，Cr，Mn，Fe，Co，Ni，Cu，Zn，Zr，Nb，Mo，Ag，Cd，Sn，Sb，Ta，W，Pb，Bi共20个(you can continue to add)

Detection object

Solid

Analytical method

Direct reading analysis + basic parameter method (FP)

Software

Remote control system, PC terminal based on Windows system / mobile terminal based on Android system can operate the instrument through software to realize data synchronization of multiple platforms (instrument, PC terminal, mobile terminal, cloud terminal). The software has the functions of data analysis, spectrum display, report printing, etc. the instrument client has the function of sending analysis report through e-mail;

Weight

≤ 1.75kg (including battery)

Microcomputer display system

1、Semi transparent and semi reflective industrial customized touch screen ≥ 5 inches

2、Resolution 1080 * 720

Power Supply

Power supply rechargeable lithium battery, standard 6800mah, voltage: 7.2V; Sustainable work up to 12 hours;

2、The instrument has the function of hot plug, delayed power off, no need to shut down when replacing the battery, and the battery has its own power display;

Charging mode

Universal adapter charging power supply;

Collimator, filter

1、Collimator of special radiation protection material, inner diameter 3mm

2、Without filter, the switching time is saved, and the background interference is deducted by the software

Front end test window

≤ 9mm * 5mm "waist" window

Camera

It has a built-in 5 megapixel HD camera function, which can take pictures of the tested object for convenient management

Test report sending method

E-mail sending, Bluetooth synchronous transmission, software synchronous transmission

Data transmission mode

WiFi, Bluetooth

Maintenance mode

Maintenance mode: remote software upgrade and diagnosis, on-site maintenance and diagnosis

User management

Multi level user management function (multiple accounts can be created to achieve person number correspondence, which is convenient for management and data tracing)

Protective cover

The instrument is equipped with a protective cover, which has the functions of instrument calibration, radiation protection and damage prevention (non-standard configuration)

Material sensing and instrument status prompt

The fuselage has material sensing function, which can intelligently identify whether there is a test object in front.

The intelligent status display lamp displays three working states through the intelligent status display lamp (red flashing indicates that the test is in progress, green flashing indicates that there is no object to be tested in front, and green long flashing indicates that there is object to be tested in front)

Operating ambient temperature and humidity

Humidity ≤ 90%

-20℃ - +60℃

Security

1、Measured value at instrument side ≤ 0.2 μ SV / h (after deducting background)

Note: the supplier must provide a copy of the handheld X-ray analyzer (leakage ray) report issued by the national authorized legal metrology institution or the national test center in the response document.

2. Multiple safety protection, no test, no radiation;

The radiation level during operation is far lower than the international safety standard, and has the function of no sample air measurement and automatic shutdown of X-ray tube.

Enclosure

Standard configuration:

1. The three proof military protection box has the functions of waterproof, dustproof and shock absorption.

2. One set of test software, instrument end, PC end and mobile phone end respectively

3. Rechargeable lithium battery * 2

4. Universal battery charging adapter * 1

Optional accessories: base type test support, protective cover
