Performance Features
1. The instrument has big current output and can select current automatically; convenient for operation.
2. Three-channel measurement, real time collection, simultaneous measuring of three resistance values and calculating three-phase resistance unbalance degree.
3. Not only able to measure three phases simultaneously, but also able to measure with single channel as traditional method; possessing temperature conversion function, convenient for use.
4. Possessing perfect protective circuit which is highly reliable.
5. Built-in calendar clock, 500 sets of data storage, retrieval and printing function.
6. Be able to set printing information such as phase sequence and tapping position of resistance.
7. Industrial plastic shell case with light weight; convenient for carrying.
8. Possessing audio discharging alarm with clear discharging indication to reduce misoperation.
Technical Indicators
1. Output current: select current automatically
2. Range ability: 0-100 Ω
3. Accuracy: 0.2%±2
4. Minimum resolution: 0.1 μΩ
5. Working temperature: -20-40℃
6. Ambient humidity: ≤80%RH, no condensation
7. Working power supply: AC220 V±10%, 50 Hz±1 Hz
8. Volume: L 400 mm*W 340 mm*H 195 mm
9. Net weight: 8 kg
