I.The instrument features

1. The instrument is controlled by a large capacity single chip microcomputer, which is stable and reliable;

2. The instrument is equipped with temperature, humidity and clock display functions, and can be customized for infrared oil temperature measurement.

3. The wide range watchdog circuit is set in the instrument to prevent the crash;

4. A variety of standard options. The instrument program is equipped with GB / t507-1986, GB / t507-2002, dl429.9, iec156 and self programming operation, which can adapt to a variety of choices of different users;

. The oil cup of the instrument is made of special glass and high polymer materials, which are processed finely to prevent oil leakage and corrosion;

6. The unique high-voltage sampling design of the instrument allows the test value to enter the A / D converter directly, avoids the error caused in the analog circuit, and makes the measurement result more accurate;

7. The instrument has over-current, over-voltage, short-circuit and other protection functions, and has strong anti-interference ability and good electromagnetic compatibility;

8. Can switch between Chinese and English at will to meet the needs of any customer;

9. 232 The data transfer；

II.Technical indicators

1. Booster capacity 1.5 KVA

2. Step up speed 0.5kv/s-5.0kv/s (increasing every 0.5) 10 gears optionalError 0.2kv/s

3. Output voltage 0-100 kV (optional)

4. Voltage accuracy (2% reading + 2 words)

5. Power distortion rate < 1%

6. Electrode gap standard 2.5mm

7. Test times 6 times (1-9 times optional)

. Static release time 900s (0-9000 s optional)

9. Interval rest time 300s (0-900s optional)

10. Mixing time 15s (0-250s optional)

11. Overall dimension: 410mm × 380mm × 370mm

III.Conditions of use

1. Ambient temperature 0-40 ℃

2. Relative humidity ≤ 85%

3. Working power AC 220V (1 ± 10%)

4. Power frequency 50 Hz (1 ± 10%)

5. Power consumption < 200 W
