Huazheng Sf6 Gas Moisture Analyzer Portable Sf6 Gas Dew Point Meter
Huazheng Sf6 Gas Moisture Analyzer Portable Sf6 Gas Dew Point Meter
Contact us
Huazheng Sf6 Gas Moisture Analyzer Portable Sf6 Gas Dew Point Meter
Huazheng Sf6 Gas Moisture Analyzer Portable Sf6 Gas Dew Point Meter
Huazheng Sf6 Gas Moisture Analyzer Portable Sf6 Gas Dew Point Meter

I.Feature And Specification

1. Feature

Portable design:light,portable,convenient to use.

Smart calibration: The sensor probe automatically calibrates to zero point to ensure the accuracy for each measurement;

Rapid measurement:when start work,it takes a short time on measurement,and get the humidity value.

Low gas consume:it just consume 2L(101.2kPa)in a test.

Self-locking joint:the self-locking joint is imported from Germany,safe,reliable,leak-proof.

Data memory:high-capacity design,save up to 200set test data.

Legible display:dew point,Micro moisture(ppm),ambient temperature,ambient humidity,time,date,battery,etc,can be read from the LCD.

RS232 port:can be connected with serial printer,carry on data printing.

Accurate measurement: increases the temperature compensation function to ensure the accuracy of measurement results under various temperature conditions.

Open calibration: This unit comes with a calibration function that allows you to calibrate the data without connecting to a computer.

2. Specification

dew point

Ranges

-80℃~+ 20℃

Accuracy

±1℃(-60℃~+ 20℃)or ±2℃(-80℃~-60℃)

Response time

63% takes 5s, 90% takes 45s / 63% takes 10s, 90% takes 240s

ambient temperature

  -40℃~+80℃

ambient humidity

  0~100RH

LCD display

  4.3 inch touch screen

Power

  AC 220V

  built-in rechargeable battery

Battery

  charge 20 hours,operating 10 hours

weight

8kg

dimension

300 mm×150 mm×300mm

operating temperature

-30℃~+60℃
