Test use

CT, electromagnetic PT

Output

0~180Vrms,12Arms,36A(peak)

Voltage measurement accuracy

±0.1%

CT transformation ratio

measuring

range

1~40000

Accuracy

±0.1%

PT transformation ratio

measuring

range

1~40000

Accuracy

±0.1%

Phase measurement

Accuracy

±2min

Resolution

0.5min

Secondary winding resistance measurement

range

0~300Ω

Accuracy

0.2%±2mΩ

AC load measurement

range

0~1000VA

Accuracy

0.2%±0.02VA

Input supply voltage

AC110V-250V,50Hz/60Hz

working environment

temperature:-10οC~50οC,  humidity:≤90%

size and weight

Size:340 mm×300 mm×140mm      weight:<7kg
