Product Model Specification

Dimensions = pressure equalizing cover diameter (R) * insulation barrel diameter (r) * total height (H)

 Main Technical Parameters Of The Product

1. Negative polarity output, 1.1 times of the maximum rated voltage. The output ripple factor is less than 0.5%.

2. Working power supply: single-phase AC 165V~245V, 50-60HZ. At the minimum input voltage, only half of the power and voltage can be output.

3. Rated output voltage: 120 kV ; rated output current: 5 mA , rated output power: 600W.

3. Host voltage measurement accuracy: ±0.5%±2 digits, minimum resolution 0.01KV, maximum display 99999.

4. Host current measurement accuracy: ±0.5% ± 2 digits, minimum resolution: 0.1 µA ; maximum display 99999.

5. Measurement accuracy of anti-shock ammeter: ±0.5% ± 2 digits, minimum resolution: 0.1 μ A; maximum display 9999.

Range: 0-5mA, 0-10mA, 0-20mA, factory standard configuration 0-5mA.

6. Working method: intermittent work, up to 30 minutes.

7. Voltage stability: random fluctuation, ≤0.5% when the grid voltage changes by ±10%.

8. Working conditions: temperature -10℃~40℃, humidity less than 90%.

9. Storage conditions: temperature -20℃~50℃, humidity less than 95%.

10. Altitude: ≤3000 meters.
